High-Rise High-Strength Steel, also known as "high-rise construction steel", is a specialized steel grade developed to meet the stringent performance requirements of modern super high-rise buildings and large-span venues. As buildings push beyond traditional height limits, conventional steel has shown limitations in load-bearing capacity, seismic resistance, and weldability. High-Rise High-Strength Steel is specifically engineered to address these challenges.
Product Advantages
-
Superior seismic performance (low yield ratio)
This is the core advantage of High-Rise High-Strength Steel. The yield-to-tensile strength ratio is typically required to be ≤0.85. This ensures sufficient plastic deformation capacity after yielding to dissipate seismic energy, functioning like a resilient spring to effectively prevent brittle structural collapse and ensure life safety.
-
Excellent weldability and processability
Through controlled carbon equivalent (CEV), High-Rise High-Strength Steel can be welded without or with minimal preheating and without post-weld heat treatment, facilitating on-site construction, improving efficiency, and reducing costs.
-
Higher load-bearing efficiency and material utilization
Under the same load conditions, high-strength steel (e.g., Q460GJ) can significantly reduce component dimensions and steel consumption. For example, in super high-rise buildings, the use of high-strength steel such as Q460GJ achieves notable structural lightweighting, saving resources and supporting green construction.
-
Reliable resistance to lamellar tearing (Z-direction performance)
For plates subjected to through-thickness tension in super high-rise buildings, High-Rise High-Strength Steel ensures Z-direction reduction of area through strict sulfur content control and special refining processes, effectively preventing lamellar cracking under complex stress conditions.
Market Applications
Specifications
| Execution Standard | Grade | Guaranteed Properties (mm) | Guaranteed Ultrasonic Testing (mm) | Delivery Condition |
| GB/T19879 | Q235GJB/GJC/GJD/GJE、Q355GJB/GJC/GJD/GJE、Q390GJB/GJC/GJD/GJE、Q420GJB/GJC/GJD/GJE、Q460GJB/GJC/GJD/GJE、Q500GJC/GJD/GJE、Q550GJC/GJD/GJE、Q620GJC/GJD/GJE、Q690GJC/GJD/GJE | 6~100 | 6~100 | AR、CR、NR、N、NT、TM、TM+T、QT |
| GB/T1591 | Q355B/C/D、Q390A/B/C/D/E、Q420A/B/C/D/E、Q460C/D/E、Q355MB/MC/MD/ME/MF、Q390MB/MC/MD/ME、Q420MB/MC/MD/ME、Q460MC/MD/ME | 6~100 | 6~100 | AR、NR、TM、N |
| GB/T1591 GB/T16270 | Q500MC/MD/ME、Q550MC/MD/ME、Q620MC/MD/ME、Q690MC/MD/ME、Q500C/D/E、Q550C/D/E、Q620C/D/E、Q690C/D/E、Q800C/D/E、Q890C/D/E、Q960C/D/E | 6~100 | 6~100 | TM、TM+T、QT |
| EN10025 | S355JOWP/J2WP、S355JOW/J2W/K2W/J4W/J5W、S420JOW/J2W/K2W/J4W/J5W、S460JOW/J2W/K2W/J4W/J5W | 6~100 | 6~100 | AR、N、TM |
| S460Q、S460QL、S460QL1、S500Q、S500QL、S500QL1、S550Q、S550QL、S550QL1、S620Q、S620QL、S620QL1、S690Q、S690QL、S690QL1 | 6~100 | 6~100 | QT | |
| ASTM A572 | Gr42、Gr50、Gr55、Gr60、Gr65 | 6~150 | 6~100 | AR、N |
| ASTM A588 | GrA、GrB、GrK | 6~100 | 6~100 | AR、N、TM |
| ASTM A871 | Gr60、Gr65 | 6~90 | 6~90 | AR、N、QT |
| ASTM A1043 | Gr36、Gr50 | 6~125 | 6~100 | AR、N、TM、QT |
| ASTM A514 | GrB、GrE、GrF、GrH、GrS | 6~100 | 6~100 | QT |
| ASTM A678 | GrA、GrB、GrC、GrD | 6~75 | 6~75 | QT |
| ASTM A852 | A852 | 6~100 | 6~100 | QT |
| ASTM A1066 | Gr70、Gr80 | 6~50 | 6~50 | TM |
| JIS G 3136 | SN400A/B/C、SN490B/C | 6~100 | 6~100 | AR、TM、N、T |
