Pipeline Steel Plate
Pipeline steel plate is a specialized steel grade used for manufacturing pipelines that transport oil, natural gas, and other energy resources. It serves as the "main artery" of the modern energy industry. Among its forms, medium and heavy plate is the core raw material for producing large-diameter, high-pressure, high-safety longitudinal welded pipes. Unlike hot-rolled coils (used for spiral welded pipes), medium and heavy plate offers greater wall thickness and superior dimensional accuracy, making it suitable for high-pressure, high-grade (e.g., X80 and above) long-distance transmission pipelines.
Product Advantages
-
High Strength for High-Pressure Transmission
Through microalloying and Thermo-Mechanical Controlled Processing (TMCP), the strength of pipeline steel has advanced from the early X52 to X80 (in mass production) and even X100 (in thousand-ton trial production). Higher strength allows pipelines to operate at elevated pressures, significantly improving transmission efficiency.
-
Excellent Low-Temperature Toughness
Maintains high impact energy at temperatures as low as -20°C or even -60°C, ensuring safe operation in cold regions.
-
Good Weldability
Ultra-low carbon (C) and carbon equivalent (CEV) designs (e.g., C≤0.09%) ensure that field weld joint performance matches the base material.
-
Outstanding Corrosion Resistance
For sour media containing H₂S, HIC/SSCC-resistant (Hydrogen-Induced Cracking / Sulfide Stress Corrosion Cracking) acid-resistant pipeline steel has been developed. This grade demands extremely high steel cleanliness.
Market Applications
-
Long-Distance Oil & Gas Transmission Trunk Lines
Such as West-East Gas Pipeline Phase II, III, IV, and China-Russia East Route.
-
Cross-Border Energy Corridors
Such as Central Asia Pipeline and China-Myanmar Pipeline.
-
Special Environment Pipelines
Such as subsea pipelines, sour media transmission pipelines, and urban pipeline networks.
Specifications
| Execution Standard | Grade | Guaranteed Properties (mm) | Guaranteed Ultrasonic Testing (mm) | Delivery Condition |
| GB/T21237 | L210/A、L245/B、L290/X42、L320/X46、L360/X52、L390/X56、L415/X60、L450/X65、L485/X70 | 6～50 | 6～50 | AR、NR、N、TM |
| API 2W | Gr50、Gr60 | 6～100 | 6～100 | TM |
| API 2H | Gr42、Gr50 | 6～100 | 6～100 | N、QT |
| GB/T21237 API Spec5L ISO3183 GB/T9711 DNV-OS-F101 | L245M/BM、L245N/BN、L245Q/BQ | 6～50 | 6～50 | TM、NR、N、QT |
| L290M/X42M、L290N/X42N、L290Q/X42Q | 6～50 | 6～50 | TM、NR、N、QT | |
| L320M/X46M、L320N/X46N、L320Q/X46Q | 6～50 | 6～50 | TM、NR、N、QT | |
| L360M/X52M/X52MS/X52MO、L360N/X52N、L360Q/X52Q | 6～40 | 6～40 | TM、NR、N、QT | |
| L390M/X56M/X56MS/X56MO、L390N/X56N、L390Q/X56Q | 6～40 | 6～40 | TM、NR、N、QT | |
| L415M/X60M/X60MS/X60MO、L415N/X60N、L415Q/X60Q | 6～40 | 6～40 | TM、NR、N、QT | |
| L450M/X65M/X65MS/X65MO、L450Q/X65Q | 6～40 | 6～40 | TM、QT | |
| L485M/X70M/X70MS/X65MO、L485Q/X70Q | 6～40 | 6～40 | TM、QT | |
| L555M/X80M、L555Q/X80Q | 6～40 | 6～40 | TM、QT | |
| L625M/X90M | 6～30 | 6～30 | TM | |
| L690M/X100M | 6～30 | 6～30 | TM | |
| GB/T30060、CDP-S-NGP-PL | WFHY360 | 6～50 | 6～50 | TM |
| WFHY415 | 6～50 | 6～50 | TM | |
| WFHY485 | 6～50 | 6～50 | TM | |
| WFHY555 | 6～50 | 6～50 | TM |
